GHS-043E 4.3″ Ethernet Operator Panel

The GHS-043E 4.3″ Ethernet Operator Panel provides an intuitive interface for controlling industrial and machine automation applications. Its compact 4.3-inch TFT colour display delivers a crisp 800 × 480 pixel resolution with 16.77 million colours. A bright LED backlight offers 500 cd/m² of brightness and is rated for over 30,000 hours of life. The resistive 4-wire touch screen allows operators to navigate menus and adjust parameters with ease.

Powered by a fast ARM Cortex‑A7 dual-core 1 GHz processor and equipped with 256 MB of NAND Flash and 128 MB DDR3 RAM, this HMI panel ensures responsive performance and reliable operation. It includes a real‑time clock for accurate timekeeping, an Ethernet port for network connectivity, a USB PictBridge port, and a micro USB/RS‑932 programming port. Communication interfaces support COM0 (RS‑932, RS‑485 or RS‑422) and COM2 (RS‑932) for connecting to controllers and other devices.

Designed for easy mounting on machine panels, the GHS‑043E is ideal for monitoring and controlling carpet washing machines, conveyor systems and other industrial equipment. Its robust feature set and high‑quality display make it a reliable operator panel for demanding environments.

Key specifications:
• Display: 4.3″ TFT, 800 × 480 resolution, 16.77 million colours, LED backlight (500 cd/m² brightness, >30,000 h life)
• Touch screen: 4-wire resistive
• CPU: ARM Cortex-A7 dual core 1 GHz
• Memory: 256 MB NAND Flash + 128 MB DDR3
• Connectivity: Ethernet, USB PictBridge, micro USB/RS‑932 for program loading
• Communication ports: COM0 supports RS‑932/RS‑485/RS‑422; COM2 supports RS‑932
• Real‑time clock for timekeeping and scheduling
• Suitable for industrial control applications including GarMak carpet washing machines
